M8199A ARBITRARY WAVEFORM GENERATOR
Research Services:
The Keysight M8199A arbitrary waveform generator (AWG) has the highest sample rate and the widest bandwidth in its class with up to four synchronized channels operating simultaneously in one module
- Up to 70 GHz analog bandwidth
- Built-in frequency and phase response calibration for clean output signals
- 6 bits ENOB, DC to 50 GHz, Fs 100 GSa/s
- Intrinsic jitter: < 75 fs
- Continuous sample rate range: 100 to 128 GSa/s resp. 200 to 256 GSa/s
- Up to 1.4 Vpp differential output voltage @128 GBd
- Transition time (20/80) as low as 5 ps
- Channel-to-channel skew adjustment with 25 fs resolution
- Synchronization of up to 16 channels across 4 modules
- < 140 dBc wideband phase noise > 1 MHz
- 512 KSa / 1 MSa of waveform memory per channel
Expertise:
- Analog bandwidth up to 70 GHz
- Continuous sample rate range at 100 to 128 GSa/s (4-channel), or at 200 to 256 GSa/s (2-channel)
- Synchronization of up to 16 channels across 4 modules (128 GSa/s) or up to 8 channels across 4 modules (256 GSa/s)
- Built-in frequency and phase response calibration for clean output signals
Research Services:
The Keysight M8199A arbitrary waveform generator (AWG) has the highest sample rate and the widest bandwidth in its class with up to four synchronized channels operating simultaneously in one module
- Up to 70 GHz analog bandwidth
- Built-in frequency and phase response calibration for clean output signals
- 6 bits ENOB, DC to 50 GHz, Fs 100 GSa/s
- Intrinsic jitter: < 75 fs
- Continuous sample rate range: 100 to 128 GSa/s resp. 200 to 256 GSa/s
- Up to 1.4 Vpp differential output voltage @128 GBd
- Transition time (20/80) as low as 5 ps
- Channel-to-channel skew adjustment with 25 fs resolution
- Synchronization of up to 16 channels across 4 modules
- < 140 dBc wideband phase noise > 1 MHz
- 512 KSa / 1 MSa of waveform memory per channel
Expertise:
- Analog bandwidth up to 70 GHz
- Continuous sample rate range at 100 to 128 GSa/s (4-channel), or at 200 to 256 GSa/s (2-channel)
- Synchronization of up to 16 channels across 4 modules (128 GSa/s) or up to 8 channels across 4 modules (256 GSa/s)
- Built-in frequency and phase response calibration for clean output signals
Contact
SAL Linz
M8199A ARBITRARY WAVEFORM GENERATOR
The M8199A arbitrary waveform generator (AWG) provides a high-performance signal source for arbitrary signals, enabling development of designs of 128 GBaud and above. All details: https://www.keysight.com/us/en/product/M8199A/arbitrary-waveform-generator-128-256-gsas.html
